Pallet Wrapping Machine
Pallet Wrapping with complete performance control!
Pallet Wrapping Machines are crucial for securing palletized loads with stretch film, protecting them from damage during transit. These machines come in various configurations, including turntable and arm styles, to accommodate different pallet sizes and shapes. They enhance load stability and optimize film usage, making them cost-effective solutions for warehouses and distribution centres. We manufacture packaging machines as well as consumables that you require for industrial-grade packaging. Our Stretch films are known to expand and cling to save you packaging costs along with the automatic wrapping application which saves you important business time. We also ensure a unique Photo Sensor that enables height Detection for different applications.
TMD Series
PW 30
Features
- Adjustable Spring Brake With Quick Release
- Turntable Home Position
- Slow Start And Stop
- One Touch Automatic Program
- Top/bottom Wraps Selector
- 3 Bottom Wraps And 2 Top Wraps
- 4 Bottom Wraps And 3 Top Wraps
- Safety Switch To Prevent Foot Pinch
- Height Detection By Photo Sensor
Standard Specification
- Wrapping Height: 2.2m (available on 2.6m & 3.0m)
- Turntable Speed: 10 Rpm
- Loading Weight: 1500 kg
- Turntable Diameter: 1.5m (Available On 1.65m Loading Weight 1650 kg)
- Power Supply: 100v, 110v, 220v, 230v, 240v & 1-phase
- Power Consumption: 0.8kw
PW 31
Features
- 300% Power Pre-stretch: 1 Meter Film Pre-stretch To Be 4 Meters
- Home Position: The Turntable Always Stops At The Same Position
- One Touch Automatic Program
- Top Bottom Wraps Selector
- 3 Bottom Wraps And 2 Top Wraps
- 4 Bottom Wraps And 3 Top Wraps
- Height Detection By Photo Sensor
- Advanced Soft Wrapping Device On The Package Angle
- Adjustable Wrapping Tension Slow Start and Stop
Specifications
- Wrapping Height: 2.2m (Available On 2.6m & 3.0m)
- Turntable Speed: 12 Rpm
- Loading Weight: 1650kg
- Turntable Diameter: 1.5m (Available On 1.65m Loading Weight 1650kg)
- Power Supply: 100v, 110v, 220v, 230v, 240v & 1-Phase
- Power Consumption:1.2kw
PW 32
Features
- LCD Touch Screen Control Panel (Same As European No.1 Brand)
- 300% Power Pre-stretch with Quick Gear Change
- Turntable Home Position
- Slow Start and Stop
- Choices Of Automatic/Manual Mode
- Adjustable Top And Bottom Wrap Counts
- Adjustable Wrapping Tension (5 Stages)
- Adjustable Turntable/carriage Speed
- Adjustable Reinforcing Wrapping
- Top Sheet Wrapping
- 3 Memory Modes – Operator Self Program
- Password Protected Control Panel
- Trouble Shooting Shown On Screen – Advance Soft Wrapping
- One-Way Idel Roller To Allow Film To Tail Stay Outside Of Carriage When Break
- Safety Switch To Prevent Foot Pinch
- Carriage Anti-falling Device
- Height Detection By Photo Sensor
Specification
- Wrapping Height: 2.2m (Available On 2.8m & 3.0m)
- Turntable Speed: 12 Rpm
- Loading Weight: 1850kg
- Turntable Diameter: 1.5m (Available On 1.85m- 1850kg Loading)
- Power Consumption: 1.2kw
- Power Supply: 100v, 110v, 220v, 230v, 240v & 1-Phase
